1000bar Ultra High Pressure Water Jetting System with 85L/min Flow Rate and 132KW Motor Power Hydro Blasting Unit
| MOQ: | 1 Set |
| Price: | USD 28,000 - 42,000 / Set |
| Standard Packaging: | Heavy-duty reinforced steel frame crate with individual module protection, vacuum-sealed moisture barriers, shock-absorbing mounts |
| Delivery Period: | 30-45 working days after deposit |
| Payment Method: | T/T,L/C |
| Supply Capacity: | 20 Sets per Month |
Detail Information
Place of Origin
Henan, China
Brand Name
XUZHIYANG
Certification
CE,
Model Number
XZY-1000-85
Max Pressure:
1000 Bar (14,500 PSI)
Water Flow Rate:
85 L/min (22 GPM)
Total Motor Power:
132 KW (Dual 66KW + 66KW)
Pump Type:
Dual Industrial Triplex Plunger Pumps
Configuration:
Parallel Pump Modules (Expandable)
Mounting:
Containerized Or Skid Mounted
Control System:
Centralized PLC With Individual Module Control
Applications:
Hydro Demolition, Coating Removal, Concrete Scarifying
Highlight:
1000bar Ultra High Pressure Water Jetting System
,85L/min Water Flow Rate Hydro Blasting Unit
,132KW Motor Power Water Jetting Machine
Product Description
1000bar Water Jetting System
XZY-1000-85
Modular Architecture Overview
The XUZHIYANG XZY1000-85 introduces a revolutionary to ultra-high pressure water jetting. Unlike traditional systems where you must purchase the full capacity upfront, this modular design allows you to start with a single pump module (500 bar / 42 L/min / 66KW) and later expand by adding a second module to double your capacity to 1000 bar / 85 L/min / 132KW. This approach significantly reduces initial capital investment while providing a clear growth path as your business scales.
Modular Configuration Options
| Configuration | Single Module | Dual Module | Multi Module |
|---|---|---|---|
| Pressure | 500 bar | 1000 bar (in series) | 1500+ bar |
| Flow Rate | 42 L/min | 85 L/min (parallel) | 120+ L/min |
| Motor Power | 66 KW | 132 KW | 200+ KW |
Advantages of Modular Design
- Reduced Initial Investment: Purchase a single module now, add more as revenue grows
- Risk Mitigation: If one module requires maintenance, the other continues operating
- Flexible Deployment: Modules can operate independently for multiple simultaneous jobs
- Easy Transport: Single modules are lighter and more compact for site mobilization
- Future-Proof: Modular platform supports future pump upgrades and new accessories
- Simplified Maintenance: Individual module servicing without complete system downtime
Industrial Applications
- Concrete hydro-demolition and bridge deck scarifying
- Industrial coating and epoxy removal at scale
- Ship hull and marine structure UHP cleaning
- Petrochemical tank and reactor internal cleaning
- Steel mill scale removal and surface preparation
- Large-scale pipeline and sewer jetting operations
Scale your water jetting business with modular confidence. Contact us for a phased investment plan.
